International 435 445 — 84 pages — Manual Code: 1095120R5
Table of Content:
INTRODUCTION
SERIAL NUMBERS
WORK SAFELY – FOLLOW THESE RULES
- Before Operating
- During Operation
- After Operation
- Transporting
- Product Graphics
ENERGY CONSERVATION FOLLOW THESE RECOMMENDATIONS PREPARING YOUR BALER FOR WORK
- General
- Hitching Baler To Tractor
- Safety Chain
- Lining Up Shaft
- Lifting Jack
- Tires
- Protective Devices On Your Baler
- Flywheel
- Needle
- Packer Finger
- Overrunning Clutch
- Friction Drive
- Pickup Slip Clutch
- Plunger Stop
- Threading Twine Tying Mechanism
- Threading Wire Twisting Mechanism
OPERATION OF YOUR BALER
- Operational Check
- Operating Speed
- Pickup Height
- Pickup Cover
- Pickup Feed Auger
- Packing Fingers
- Baler Chamber Tension
- Hydraulic Bale Tension Device
- Bale Length
- Bale Weight
- Bale Chamber Extension
- Bale Turner
CARE OF YOUR BALER
- Pickup And Feeder
- Auger
- V-Belt Drive
- Pickup Balancing Spring
- Pickup Drive
- Plunger Adjustment
- Plunger Knife Clearance
- Feed Opening Knife Guide
- Upper Plunger Wear Pad
- Shimming Plunger Upper Right Block
- Sharpening Plunger And Stationary Knives
- Metering Wheel Adjustment
- Twine Baler Knotter
- Nomenclature
- Tying Mechanism
- Knotter Operation
- Knotter Position
- Gauge Surface To Breast Plate
- Knotter Adjusting Collars
- Knotter Hook
- Disk Timing
- Keeper Blade Adjustment
- Delay Surface
- Twine Knife
- Removal Of Knotter Frame Assembly
- Twine End Retainer Spring
- Twine Needle Adjustment
- Twine Tension
- Lok Twist Baler Twister Nomenclature
- Twister Mechanism
- Twister Operation
- Adjusting and Servicing Twister
- Gauge Surface To Base Plate
- Wire Disk Timing
- Keeper Blade To Disk Spacing
- Delay Surface
- Wire Shear Knife
- Removal Of Twister Frame Assembly
- Needle Adjustment
- Timing The Baler
STORAGE OP YOUR BALER
- Storage
- Remvoing From Storage
OPTIONAL EQUIPMENT
- Trailer Hitch And Bale
- Chute
- Safety Lighting
- Pickup Wheel
- Three-Joint Universal
- Drive Shaft
- Hydraulic Bale Tension
- Device
- Bale Turner
- Engine Shut-Off
- 10 Bale Thrower
