International 3650 Round Baler PDF

International 3650 — 84 pages — Manual Code: 1096766R3

Table of Contents:

WORK SAFELY – FOLLOW THESE RULES

• Before Operating
• During Operating
• Fire Extinguisher
• Handling Bales
• Transporting
• During Maintenance
• After Operation

ENERGY CONSERVATION

INTRODUCTION

PREPARING THE HAY FOR

BALING

• For Cornstalks
• For Combined Crop Residue

DUAL RAKE HITCH

PREPARING THE BALER FOR

WORK

• General
• Lubricate Completely
• Hitching Baler to Tractor
• Tires
• Twine System

OPERATION OF THE BALER

• Operational check
• Pickup height
• Pickup lock
• Gauge wheel
• Right Hand Gauge Wheel – Optional
• Pickup Flotation
• Operating Speed
• Making The Windrow
• Picking Up A Windrow
• Plugging Of The Baler
• Bale Formation
• Bale Compaction Pressure
• Wrapping The Bale (Electric Wrap)
• Wrapping The Bale (Mechanical Wrap)
• Bale Counter (Optional)
• Proper Baler Storage

ADJUSTING AND SERVICING

• Main Drive Shear Bolt
• Pickup Drive Belt
• Pickup Speed
• All Drive Chains
• Windguard Removal
• Twine Cut-Off (Mechanical Wrap)

ELECTRIC TWINE WRAP

• Twine Tubes
• Twine Cut-Off — Both Sides
• Jam Arm and Trigger Plate Clearance
• Bale Counter
• Twine Guide Brackets
• Bale Density Springs
• Latch Rods
• Bale Density Switch (Mechanical Wrap)
• Bale Density Switch (Electric Wrap)
• Cylinder Stops
• Belt Tension – Forming Belts
• Belt Tension – Bottom Belts
• Belt Adjustment
• Scraper Adjustment
• Belt Adjustments
• Endless Belt Replacement
• Upper Roll Removal
• Drive Roll Removal
• Idler Roll Removal
• Roll and Belt Installation
• Endless Belt Repair
• Pickup Cam Follower Bearings
• Pickup Teeth and Tooth
• Shaft Bearings

STORAGE

• End of Season Storage
• Removing from Storage

TROUBLESHOOTING

TORQUE DATA

SET UP INSTRUCTIONS

• Hitch. Jack and Power Shaft
• Baler Control Box (Electric Wrap)
• Fire Extinguisher
• Baler Run-In
• Lighting Package

LUBRICATION

SPECIFICATIONS

METRIC MEASUREMENTS

SERVICE

• Gear Box
• RPM Conversion
• Electrical
