Case IH 544 656 Series Hydrostatic Drive tractor H70 H80 Trouble shooting Manual


Case IH 544 656 Series Hydrostatic Drive tractor H70 H80 Trouble shooting Manual

Out of stock


International Case IH 544 656 Hydrostatic tractor — 44 pages — manual code: GSS-1405



Do’s and Don’ts of Hydrostatic Tractor Servicing

Tools Required for Field and Shop Service Kit for Servicing 656 & 544 Series and 3514 & 3616 Hydrostatic Tractors

  • Tools Required for Checking Charge Flow and Running Clean-Up Procedure
  • Tools Required to Check all Pressures at the Same Time, and for Isolating Drive Control and Foot-N-Inch Valves
  • Tools Required for Servicing Check Valves, Relief Valves and Servo Cylinders
  • Miscellaneous Tools and Supplies

Basic Explanation of Each System Component and Possible Malfunctions

  • High-Low Range Transmission
  • S-R Lever and Effects of Poor S-R Lever Adjustment
  • Center Section Shuttle Valve and Possible Malfunctions
  • High Pressure Relief Valves
  • Parts Which Can Cause High Pressure Valves to Open
  • Drive Control Valve
  • Foot-N-Inch Valve
  • Servo Cylinders (How They Operate)
  • Servo Cylinders (Possible Malfunctions)
  • Pump Servo
  • Motor Servo

Step-By-Step Checks During Trouble Shooting

  • Step-By-Step Check Outline
  • General
  • Checking Statically
  • Test Driving
  • Checking Anti-Coast Valve
  • Checking Reverse Deceleration
  • Other Possible Malfunctions Which May Show Up During Driving Test
  • Checking for Speed of Servo Response
  • Further Checks After Test Driving

Checking Charge Flow on Tractors Equipped with Recirculating Filter Parts Accessory No. 530 976 R91

Clean-Up Procedure After Major Overhaul

Clean-Up Procedure for Tractors with Recirculating Filter

Installing Recirculating Filter

Checking Complaints of High Fuel Consumption or High Temperatures

Parts Which Can Be Removed Without Splitting the Tractor
